Oil Seed Presses

Aquahelios Kern Kraft  Oil Seed Presses.

Aquahelios Kern Kraft Oil Seed Presses have been built to the highest standards and feature the latest German engineering technology. Presses are compact and ready for work on arrival, only needing an electrical connection. Maintenance is minimal; they are easy to dismantle and reassemble after cleaning which makes them ideal for culinary oil production. We offer a full consultation and training program, which will get you up and running quickly.

Our Oil Seed Presses are suitable for use with the following applications:

Rapeseed, Sunflower Seed, Soybean, Linseed, Pleasure of Gold, Pumpkin Seed, Poppy Seed, Rubberseed, Loofah, Potato Chips, Kahai, Safflower, Candlenut, Marula, Chia, Moringa, Soldier Fly Larvae, Black Cumin, Apple Seed, Sesame Seed, Karitè/Shea, Peanut, Jatropha/Physic Nut, Hemp, Milk Thistle, Hazelnut, Walnut, Sea Buckthorn, Lemon Seed, Elderberry Seed, Evening Primrose, Pomegranate Seed, Grape Seeds, Mustard, Argan, Cottonseed, others on request

KK Oil prince F Universal

  • Seed capacity:  10-15 kg/h.
  • Engine power: 2.2 kW.
  • Rpm (revolutions per minute) | Voltage:  15-60 ¹/min | 230 V, single phase | 50/60 Hz.
  • Dimensions (LxWxH): 900 x 250 x 450 mm.
  • Electric power consumption: at rated power (Rapeseed) approx. 0.8 kW/h.
  • Lightweight commercial oil press.
  • Uses exactly the same press screws and barrels as the KK20 and KK40
  • Weight: 80kg
KK Prince Further Information & Prices
KKOil Prince F Universal Seed Oil Press with a seed capacity of 10-15 kg/h
KKO Prince Brochure PDF
KK20 F Universal Seed Oil Press With A Seed capacity of 20 kg/h.
KK20F Universal Brochure PDF

KK20 F Universal Oil Seed Presses

  • Seed capacity: 20 kg/h.
  • Engine power: 2 kW.
  • Rpm (revolutions per minute) 15 – 70 1/min.
  • Voltage: 110V-2ph | 230V-1ph | 230V-3ph | 400V-3ph | 460/480V-3ph.
  • Dimensions (LxWxH): 480 x 480 x 620 mm .
  • Electric power consumption: at rated power (Rapeseed) approx. 0,8 kW/h.
  • Suitable for 24/7 production.
  • Cake output as pellets.
  • Can be configured to press most oil bearing seeds and nuts.
  • Weight: 120kg.
  • Application: all seeds listed above and in addition: Strawberry Seed, Sea Buckthorn, Coffee Bean, Lemon Seed, Date stones, Elderberry Seed, Raspberry Seed, Amaranth, Prickly Pear, Evening Primrose, Neem, Pepper Seed, Nutmeg, Pomegranate Seed, Rosehip Seed, Grape Seed, others on request
KK20F Further Information & Prices

KK20 F Special Oil Seed Presses

  • Seed capacity: 20 kg/h.
  • Engine power: 3 kW.
  • Rpm (revolutions per minute) 15 – 70 1/min.
  • Voltage: 110V-2ph | 230V-1ph | 230V-3ph | 400V-3ph | 460/480V-3ph.
  • Dimensions (LxWxH): 480 x 480 x 620 mm .
  • Electric power consumption: at rated power (Rapeseed) approx. 0,8 kW/h.
  • Suitable for 24/7 production.
  • Cake output as pellets.
  • Can be configured to press most oil bearing seeds and nuts.
  • Weight: 120kg.
  • Application: all seeds listed above and in addition: Strawberry Seed, Sea Buckthorn, Coffee Bean, Lemon Seed, Date stones, Elderberry Seed, Raspberry Seed, Amaranth, Prickly Pear, Evening Primrose, Neem, Pepper Seed, Nutmeg, Pomegranate Seed, Rosehip Seed, Grape Seed, others on request
KK20 S Further Information & Prices
KK20 F Universal Seed Oil Press With A Seed capacity of 20 kg/h.
KK20 Special Brochure PDF
KK40 F Universal Seed Oil Press With A Seed capacity of 40 kg/h.
KK40F Universal Brochure PDF

KK40 F Universal Oil Seed Presses

  • Seed capacity: 40 kg/h.
  • Engine power: 3.0 kW.
  • Rpm (revolutions per minute) 15-70 l/min.
  • Voltage: 110V-2ph; 230V-1ph; 230V-3ph; 400V-3ph; 460/480V-3ph.
  • Dimensions (LxWxH):900 x 550 x 600 mm.
  • Electric power consumption: at rated power (Rapeseed) approx. 1,6 kW/h.
  • Suitable for 24/7 production.
  • Cake output as pellets.
  • Can be configured to press most oil bearing seeds and nuts.
  • Weight: 200kg.
  • Industrial Unit: Capable of running 24/7/365.
  • Application: all seeds listed above and in addition: Strawberry Seed, Sea Buckthorn, Coffee Bean, Lemon Seed, Date stones, Elderberry Seeds, Raspberry Seeds, Amaranth, Prickley Pear, Evening Primrose, Neem, Pepper Seed, Nutmeg, Pomegranate seed, Rosehip Seed, Grape Seed, others on request.
KK40FU Further Information & Prices

KK40 F Special Oil Seed Presses

  • Seed capacity: 40 kg/h.
  • Engine power: 4.0 kW.
  • Rpm (revolutions per minute) 15-70 l/min.
  • Voltage: 110V-2ph; 230V-1ph; 230V-3ph; 400V-3ph; 460/480V-3ph.
  • Dimensions (LxWxH):900 x 550 x 600 mm.
  • Electric power consumption: at rated power (Rapeseed) approx. 1,6 kW/h.
  • Suitable for 24/7 production.
  • Cake output as pellets.
  • Can be configured to press most oil bearing seeds and nuts.
  • Weight: 200kg.
  • Industrial Unit: Capable of running 24/7/365.
  • Application: all seeds listed above and in addition: Strawberry Seed, Sea Buckthorn, Coffee Bean, Lemon Seed, Date stones, Elderberry Seeds, Raspberry Seeds, Amaranth, Prickley Pear, Evening Primrose, Neem, Pepper Seed, Nutmeg, Pomegranate seed, Rosehip Seed, Grape Seed, others on request.
KK40FS Further Information & Prices
KK40 F Special Seed Oil Press With A Seed capacity of 40 kg/h.
KK40F Special PDF
KK80 F Universal Seed Oil Press With A Seed capacity of 40 kg/h.
KK80F Universal PDF

KK80 F Universal Oil Seed Presses

  • Seed capacity: 80 kg/h.
  • Engine power: 5.5 kW.
  • Rpm (revolutions per minute) 15 – 60 1/min..
  • Voltage Standard Version: 400V-3phase.
  • Voltage Special Version: 110V-2ph | 230V-1ph | 230V-3ph | 460/480V-3ph.
  • Dimensions (LxWxH): 1870 x 500 x 1220 mm.
  • Electric power consumption: at rated power (Rapeseed) approx. 2,5 kW/h.
  • Cake as flakes or milling head can be fitted to give cake as a coarse meal
  • Easily adjustable and great for ‘difficult seeds’.
  • Weight: 380kg.
  • Industrial Unit: Capable of running 24/7/365.
  • Application: Rapeseed, Mustard, Sunflower Seed, Soybean, Linseed, Chia, Gold of Pleasure, Pumpkin Seed, Poppy Seed, Sacha Inchi, Rubberseed, Loofah, Potato Chips, Kahai, Safflower, Candlenut, Marula, Moringa, Soldier Fly Larvae, Hazelnut, Walnut, Macadamia, Argan, Black Cumin, Apple Seed, Hemp, Sesame, Karité/Shea Nut, Peanut, Jatropha/Physic Nut, Milk Thistle, others on request (20-70% oil content).
KK80F Further Information & Prices

KK100 F Universal Oil Seed Presses

  • Seed capacity: 100 kg/h.
  • Engine power: 7.5 kW.
  • Rpm (revolutions per minute)15 – 60 1/min.
  • Voltage Standard Version: 400V-3phase.
  • Voltage Special Version: 110V-2ph | 230V-1ph | 230V-3ph | 460/480V-3ph.
  • Dimensions (LxWxH): 1700 x 600 x 1200 mm.
  • Electric power consumption: at rated power (Rapeseed) approx. 3 kW/h.
  • Easily adjustable and great for ‘most seeds’.
  • Different screw profiles available for different seeds.
  • Weight: 380kg.
  • Industrial Unit: Capable of running 24/7/365.
  • Different screw profiles available for different seeds.
  • Application: Rapeseed, Mustard, Sunflower, Soybean, Linseed, Gold of Pleasure, Hemp, Grape Seed, Black Cumin, Pepper Seed, Safflower, Rosehip Seed, Apple Seed, Amaranth, Prickly Pear, Jatropha, Baobab Peeled, Poppy Seed, Moringa, Milk Thistle, Strawberry Seed, Sea Buckthorn, Coffee Bean, Lemon Seed, Date Stones , Nutmeg, Elderberry Seed, Raspberry Seed, Pomegranate Seed, Rice Husk, Coconut-meat, others on request.
KK100F Further Information & Prices
KK100 F Universal Seed Oil Press With A Seed capacity of 100 kg/h.
KK100F Universal PDF
KK100 F Universal Seed Oil Press With A Seed capacity of 100 kg/h.
KK100F Universal HD PDF

KK100 F Universal HD Oil Seed Presses

  • Seed capacity: 200 kg/h.
  • Engine power: 9.2 kW.
  • Rpm (revolutions per minute)15 – 60 1/min.
  • Voltage Standard Version: 400V-3phase.
  • Voltage Special Version: 110V-2ph | 230V-1ph | 230V-3ph | 460/480V-3ph.
  • Dimensions (LxWxH): 1800 x 600 x 1200 mm.
  • Electric power consumption: at rated power (Rapeseed) approx. 5 kW/h.
  • Easily adjustable and great for ‘most seeds’.
  • Different screw profiles available for different seeds.
  • Weight: 470kg.
  • Industrial Unit: Capable of running 24/7/365.
  • Different screw profiles available for different seeds.
  • Application: Rapeseed, Mustard, Sunflower, Soybean, Linseed, Gold of Pleasure, Hemp, Grape Seed, Black Cumin, Pepper Seed, Safflower, Rosehip Seed, Apple Seed, Amaranth, Prickly Pear, Jatropha, Baobab Peeled, Poppy Seed, Moringa, Milk Thistle, Strawberry Seed, Sea Buckthorn, Coffee Bean, Lemon Seed, Date Stones , Nutmeg, Elderberry Seed, Raspberry Seed, Pomegranate Seed, Rice Husk, Coconut-meat, others on request.
KK100F Further Information & Prices

KK500 F Universal Oil Seed Presses

  • Seed capacity: 500 kg/h.
  • Residual oil content in the press cake *  7 – 11 %
  • Temperature of oil outlet* 35 – 50 °C.
  • Temperature of cake outlet* 40 – 95 °C.
  • Dimensions (LxWxH):  3029 x 860 x 883mm.
  • Engine Power: 18,5 kW.
  • Engine Drive: Gear Motor.
  • Power Supply: 3 Phase, 50/60 Hz, 230 V, 400 V, 460/480 V
  • Weight: 1700kg.
  • Industrial Unit: Capable of running 24/7/365.
  • Different screw profiles available for different seeds.
  • Application: Rapeseed, Mustard, Sunflower, Soybean, Linseed, Gold of Pleasure, Pumpkin Seed, Hemp, Poppy Seed, Moringa, Nutmeg, Black Seed, Safflower, Apple Seed, Karité/Shea Nut, Sesame Seed, Peanut, Jatropha/ Physic Nut, Elderberry, Cocoa, Copra/Coconut, Jojoba, Walnut, Hazelnut, Almond, Rice Brain, Seedlings (Corn, Wheat, Rice) others on request.
KK500F Further Information & Prices
KK500 F Universal Seed Oil Press with a Seed capacity 500 kg/h
KK500F Universal PDF
KK1000F Oil Seed Press with a seed capacity of 1000 kg/h
KK1000F Universal PDF

KK1000 F Universal Oil Seed Presses

  • Seed capacity: 1000 kg/h.
  • Residual oil content in the press cake *  11 – 16%.
  • Temperature of oil outlet* 35 – 50 °C.
  • Temperature of cake outlet* 40 – 95 °C.
  • Dimensions (LxWxH):  3500 x 1200 x 1000mm.
  • Engine Power: 40 kW.
  • Engine Drive: Gear Motor.
  • Power Supply: 3 Phase, 50/60 Hz, 230 V, 400 V, 460/480 V
  • Weight: 2000kg.
  • Industrial Unit: Capable of running 24/7/365.
  • Application: Rapeseed, Mustard, Sunflower, Soybean, Linseed, Gold of Pleasure, Pumpkin Seed, Hemp, Poppy Seed, Moringa, Nutmeg, Black Seed, Safflower, Apple Seed, Karité/Shea Nut, Sesame Seed, Peanut, Jatropha/ Physic Nut, Elderberry, Cocoa, Copra/Coconut, Jojoba, Walnut, Hazelnut, Almond, Rice Brain, Seedlings (Corn, Wheat, Rice) others on request.
KK1000F Further Information & Prices
